Air Powered Strapping Machine

Key Facts

Model no SM-APA
Tape material PP or PET plastic
Tape width 13 - 19 or 19 - 25 mm
Tape thickness 0.6 - 1.2 mm
Delivery Free delivery available
Options & Prices

13 - 19 mm tape

£195.00
✅ In stock

19 - 25 mm tape

£225.00
✅ In stock

Overview

In a nutshell: Pneumatic strapping machine for PP or PET tapes

The A series strapping machines use a 13 - 19 mm or 19 - 25 mm PP or PET tape. Powered by compressed air and capable of producing up to 3500 N of strapping tension which can easily cope with the packaging needs of various heavy items, ensuring the firmness and stability of the packaging.
Features:

  • Press the tension button to tighten the strap.
  • Push down and hold the welding lever to bond the strap using friction stir welding.

Typical uses include:

  • Pallets
  • Construction materials

The key features of the SM-APA

In Use

Specifications

Machine dimensions 280 x 160 x 180 mm (l × w × h)
Machine weight 3.8 Kg
Strap tension 350 Kg
Bonding method Friction stir weld
Operation Automatic
Power Compressed air at 0.5-0.8Mpa
Tape Requirements
Tape material PP or PET plastic
Tape width 13 - 19 or 19 - 25 mm
Tape thickness 0.6 - 1.2 mm
The basic dimensions of the Air Powered Strapping Machine

Compatible Tapes

13 mm PET Strapping Tape

Tape Specifications

Tape material PET Plastic
Roll length 1000 M
Tape thickness 0.8 mm
Tape strength 200 Kg

16 mm PET strapping tape

Tape Specifications

Tape material PET Plastic
Roll length 1000 M
Tape thickness 1.0 mm
Tape strength 380 Kg

19 mm PET strapping tape

Tape Specifications

Tape material PET Plastic
Roll length 750 M
Tape thickness 1.0 mm
Tape strength 400 Kg

13 mm PP Strapping Tape

Tape Specifications

Tape material PP Plastic
Roll length 1000 M
Tape thickness 0.6 mm
Tape strength 100 Kg

15 mm PP Strapping Tape

Tape Specifications

Tape material PP Plastic
Roll length 1000 M
Tape thickness 1.0 mm
Tape strength 250 Kg

Accessories

200 mm Core Strapping Tape Cart

The 200 mm Core Strapping Tape Cart
Wheeled, floor standing dispenser for strapping tapes with 200 mm inner core diameter

Heavy Duty 200 mm Core Strapping Tape Cart

The Heavy Duty 200 mm Core Strapping Tape Cart
Heavy duty, wheeled, floor standing dispenser for strapping tapes with 200mm inner core diameter

Adjustable Core Strapping Tape Cart

The Adjustable Core Strapping Tape Cart
Wheeled, floor standing cart & dispenser for strapping tapes with 200 or 400 mm inner core diameter.

Heavy Duty Adjustable core strapping tape cart

The Heavy Duty Adjustable core strapping tape cart
Heavy duty, wheeled, floor standing cart & dispenser for 200, 250, 400 mm core strapping tapes

Frequently Asked Questions

Yes, all our machines come with a 12-month warranty. All our banding and strapping machines are supplied with a 12-month return-to-base warranty covering manufacturing defects. If something goes wrong, please contact us and we'll help establish the cause and the most practical way to put it right.

An ordinary tape jam isn't a warranty fault, but we're happy to help. Warranty strictly covers manufacturing defects in the machine's components—for example, if a motor burns out or a circuit board fails. A tape jam is an operational event, much like a paper jam in a printer or a staple jamming in a stapler. It is a temporary blockage caused by the consumable, rather than a mechanical failure of the machine itself.

No, we do not offer trial or loan machines, though we can record a custom video demo for you To keep our machine prices as low as possible, we are not in a position to lend equipment out to customers. However, if you are unsure how a machine will perform, we are happy to record a short demonstration video using your own products or samples. Please email us to arrange this.

No, we only offer return-to-base servicing to keep our prices as low as possible. Sending an engineer out to your premises would significantly increase our overheads and force us to raise our machine prices. To give you the best value for money, all of our warranties and repairs operate strictly on a return-to-base basis. However, our team is happy to help troubleshoot minor issues via email or WhatsApp.

No, every technical detail and specification we have is already listed on this page. As an online retailer, we want you to have everything you need to make an informed decision right away. We publish all available specifications, dimensions, and details directly on our product pages so nothing is hidden. If you have a specific question about whether this machine will suit your needs, please get in touch and we will do our best to help.
